5G Bullet Network Camera
Industrial-grade 5G bullet network camera with ultra-low latency HD video, edge AI support, RS232/RS485 interfaces, and IP67 protection for smart city, factory, and outdoor surveillance applications.
Need bulk pricing or technical details? Express Interest
- The 5G Bullet Network Camera is an industrial-grade IoT surveillance solution designed for high-speed, low-latency video transmission in demanding environments. Powered by an industrial processor and 5G/4G connectivity, it delivers ultra-high-definition video with advanced edge intelligence, wide dynamic range imaging, and robust environmental protection. With integrated RS232 and RS485 interfaces, embedded RTU functionality, and support for AI-based video analytics, this camera is ideal for smart cities, industrial automation, traffic monitoring, critical infrastructure security, and large-scale IoT deployments. Its rugged IP67 metal enclosure, wide temperature tolerance, remote management capabilities, and flexible mounting options ensure reliable 24×7 operation in outdoor and industrial installations.
Technical Specifications
Camera & Imaging
- Image Sensor
- 1/2.8-inch Progressive Scan CMOS
- Maximum Resolution
- 1920 × 1080 (Full HD)
- Minimum Illumination
- 0.002 Lux (Color), 0 Lux with IR On
- Shutter Speed
- 1/100000s to 1/5s
- Infrared Distance
- Up to 150 meters
- Wide Dynamic Range
- Up to 140 dB Super WDR
- Day/Night Mode
- ICR Auto Switch
Lens Options
- Fixed Lens
- 2.8 mm @ F2.0
- Motorized Zoom Lens
- 16× AF Motorized Lens (Optional)
- Field of View
- Up to 123° Horizontal (Lens dependent)
Video & Compression
- Video Compression
- H.265 (HEVC), H.264, MJPEG
- Frame Rate
- Up to 30 fps at Full HD
- Bit Rate
- 16 Kbps to 16 Mbps (CBR/VBR Adjustable)
- Image Controls
- Brightness, Contrast, Saturation, Sharpness
Network & Connectivity
- Cellular Network
- 5G NR (SA & NSA), 4G LTE FDD/TDD (Optional)
- Ethernet Port
- 1 × RJ45 10/100 Mbps
- Supported Protocols
- IPv4/IPv6, TCP, UDP, RTP, RTSP, HTTP/HTTPS, SNMP, NTP
- Network Storage
- NAS Support (NFS, SMB/CIFS)
Interfaces & I/O
- Serial Interfaces
- RS232, RS485
- Digital Inputs / Outputs
- 2 × DI, 2 × DO (Optional)
- Relay Outputs
- 2 × Relay (Optional)
- Audio I/O
- 1 Input / 1 Output (Optional)
- ADC
- 2 × 12-bit ADC
Storage & Analytics
- Local Storage
- MicroSD / SDHC / SDXC up to 128 GB
- AI Video Analytics
- Motion Detection, Line Crossing, Intrusion, People Counting (Optional)
- Event Actions
- FTP Upload, Email Alerts, SD Card Recording
Power & Environmental
- Power Supply
- PoE (802.3at) or DC 12–60 V
- Power Consumption
- < 9 W (Max)
- Operating Temperature
- -35 °C to +75 °C
- Ingress Protection
- IP67 Weatherproof
Mechanical & Installation
- Enclosure
- Industrial Metal Housing
- Dimensions
- 260 × 130 × 110 mm
- Weight
- Approx. 4.5 kg
- Mounting Options
- Pole Mount, Wall Mount, DIN Rail (Optional Accessories)
Security & Management
- Remote Management
- Web UI, HTTPS, SSH, SNMP, SYSLOG
- System Protection
- Watchdog, Over-voltage & Reverse Polarity Protection
- Standards Compliance
- ONVIF Profile S, GB/T28181, MQTT, Modbus RTU
Helping Your Business
Discover how this device can transform your daily operations.
Off-Grid Perimeter Security
Off-Grid Perimeter Security
Secure remote construction sites, agricultural land, and energy substations where wired power and internet are completely unavailable. The built-in lithium battery and 4G connectivity provide immediate, self-sustaining video surveillance with zero trenching required.
Perimeter Security →
Smart City Traffic Monitoring
Stream high-definition, uncompressed video directly to municipal command centers. The 5G Bullet Camera's immense bandwidth and edge AI capabilities allow for real-time license plate recognition (LPR) and vehicle counting to optimize urban traffic flow without network congestion.
Smart City Solutions →
Industrial Edge AI & Analytics
Deploy intelligent surveillance inside bustling factory floors. Using edge video analytics, the cameras autonomously detect line crossings, unauthorized intrusions, and human presence in restricted zones, instantly triggering email alerts or FTP uploads without relying on a central server.
Industrial Automation →
Legacy Sensor & IoT Integration
Merge physical security with environmental telemetry. Utilize the cameras' integrated serial ports and digital I/O channels to connect legacy alarm panels, temperature sensors, and access control relays directly into your unified 4G/5G surveillance dashboard.
IoT Integration →
Extreme Weather Surveillance
Maintain crystal-clear visibility during severe storms, blinding glares, or complete darkness. The rugged IP67 metal housing operates flawlessly down to -35°C, while the 140dB Super WDR and 150-meter IR night vision ensure high-contrast imaging in any lighting condition.
Rugged Surveillance →FAQs 5G Bullet Network Camera
Can't find what you're looking for?
Chat to supportThe 5G Bullet Network Camera is designed for industrial and outdoor surveillance applications such as smart cities, traffic monitoring, factories, critical infrastructure, and large-scale IoT security deployments.
Yes, the camera supports 5G NR (SA & NSA) and 4G LTE networks, ensuring reliable connectivity across different regions and network availability.
Yes, it features an IP67-rated industrial metal enclosure, wide temperature tolerance, and surge protection, making it suitable for continuous outdoor and industrial use.
Yes, optional AI analytics such as motion detection, intrusion detection, line crossing, and people counting are supported at the edge for faster response and reduced bandwidth usage.
The camera supports pole mounting, wall mounting, and optional DIN rail installation using compatible industrial brackets and accessories.
Yes, the camera includes RS232 and RS485 interfaces along with digital I/O and relay options, allowing integration with industrial sensors and control systems.
Yes, the camera supports secure remote management via web interface, SSH, HTTPS, SNMP, and allows remote firmware upgrades.
